Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

  • 1
  • 2
  • 3

Model Number : BF-PVC001

MOQ : 20set

Price : $10.8-12/set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000SETS/PER YEAR

Delivery Time : 30 working days

Packaging Details : wooden carton

Productivity : 100L/Hour

Filter cartridge length : 5, 10, 20, 30, 40, 60 inch, OEM

Dimension : 0'' 20'' 30''' 40''

Micron rating : 0.1, 0.2, 0.3, 0.45, 0.65, 1.0, 3.0, 5.0, 10 um

Contact Now

Materials Of Construction
Filter Media:
Polypropylene Membrane
Micron Rating:
0.1, 0.2, 0.45, 0.65, 1.0, 3.0, 5.0, 10, 20, 30, 50, 100um
Support Layers:
Polypropylene
Cage, Core, End Cap:
Polypropylene
Seal Method:
Thermal Bonded, No Adhesives
O-rings/Gaskets:
Silicone, Nitrile, EPDM, Viton, etc
Cartridge Dimensions
Outer Diameter:
69mm
Inner Diameter:
33mm
Length:
5, 10, 20, 30, 40 Inch
Filtration Area(m2):
0.65 m2 per 10"
Operating Conditions
Normal Operating Temp.:
Up to 60℃
Max. Operating Temp.:
80℃
Max. Differential Pressure
Normal Flow:
4.2 bar at 25℃
Reverse flow:
2.1 bar at 25℃
PH Value compatibility:
1-13
Sterilization:
Steam Sterilization for 30 minutes at 121±2 ℃, Cumulative Time:15 hours
Flush with hot water at 82℃(180℉) for 30 minutes, at P≤1.0 bar (14psi)--Recommended.
Cartridge Safety
Endotoxin:
<0.25 EU/ml
Extractables:
<0.03 g/10"

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM
Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Polypropylene Membrane 50 Microns Pleated Filter Cartridge 30 Inch 222 SOE EPDM

Q1 : Where is your factory located?
A1 : Qingdao crowns machinery co.,ltd is located at Huangdao district ,Qingdao city, China

Q2 : Are you an integrated supplier for
industrial filter machine ?
A2 : Yes, we can provide the complete solution line to customer according to customer’s requirement.

Q3 : How about the quality control in your factory?
A3 : Qingdao crowns has the SOP (Standard Operation Procedure) and all the production step must follow

up this SOP. Every machine needs at least automatic running over 72 hours and must be inspected carefully

before shipment.

Q4 : Will you offer the pre-sales service?
A4 : Yes, we have an experienced pre-sales team to support customers not only including machine, technology

also water.

electrical,machine layout in factory, etc.

Q5 : What about the after-service? Will you send your engineer to my country to help commission and install the

machine?
A5 : Surely, we have many experience technical engineers for oversea service, they would help you install machine

and support training to workers also.

Q6 : What is the delivery time of the machine?
A6 : Actually, the delivery time of the machines is depended on the machine options. Normally, the delivery

time of standard machine could be within 10-30 days

Q7 : What is the warranty of the machine ?
A7 : The whole machine’s warranty period is 12 months and key parts will be depended.

Q8 : Do you provide any spare parts with machine?
A8 : Yes, CROWNS will provide one set standard spare parts to customer according to different machines
